Electrical and Electronics Control Panel Cooling Systems for Entertainment and Sports Venue Applications
EIC Solutions offers a wide range of standard and custom cooling solutions designed to protect sensitive electronics and meet the demands of a broad range of entertainment and sports venue environments – including extreme heat, high humidity and precipitation.
When reliability and low maintenance are paramount, EIC’s control panel cooling systems are there to keep the equipment running smoothly by protecting LED scoreboards, sound and lighting equipment, audio/video systems, security cameras and other electrical/electronic equipment from damaging heat, dust, moisture, and corrosion.
The Need for Electronic Control Panel Cooling
The sports industry has faced a number of poor seasons in the midst of the most recent recession, with the proliferation of media choices and higher ticket prices translating into reduced numbers of fans at the gate. Revenue, however, is expected to improve in the coming years as sports teams seek to lure more patrons by investing in technology – state-of-the-art video boards, Wi-Fi, various smart phone apps and other game day enhancements. Also, the improved economy is projected to help raise consumer confidence, causing demand for sports and entertainment to rise substantially.
This need to add bigger and more interactive enhancements to sports and entertainment venues has dramatically increased the demand for state of the art electronic control systems to operate a wide variety of electronic scoreboards, multi-media displays, audio/video equipment, lighting and other advanced technologies. As heat fluxes continue to rise, this has presented significant challenges to keeping these systems running smoothly. The controls for these systems produce significantly higher levels of heat than previous systems and as a result are more sensitive to harsh environmental factors. Typically these electrical/electronic systems are installed in sealed enclosures making thermal overrun temperatures one of the leading causes of failure and reduction in MTBF. The removal of heat generated by these advanced electronics systems has grown to be a critical issue since these systems must often perform in high ambient temperature environments.
In addition, many of these systems utilize rack mounted electronics that were originally designed for operation in air conditioned buildings, not in harsh outdoor environments. These rack mounted systems are now being installed both indoors and outdoors in enclosures that are exposed to ambient temperatures up to 120°F and in some cases much higher. In addition to extreme temperatures, these sensitive electronic systems are also subject to the dust, dirt, moisture, corrosion and vibration typical of the harsh conditions found in sports and entertainment environments.
In order to effectively solve these complex cooling problems, the designers and engineers for professional and college sports stadiums as well as concert and entertainment venues are turning to EIC’s thermoelectric cooling systems as an ideal solution when a low to moderate amount of heat must be handled in a harsh environment. Using patented solid-state technology to accomplish temperature change, thermoelectric coolers eliminate the need for refrigerants and operate with fewer moving parts. They can cool enclosures to temperatures below ambient conditions while producing little noise and vibration. Featuring reliability and a long life span coupled with flexible input power requirements and mounting arrangements, EIC’s thermoelectric air conditioners offer significant advantages over conventional cooling methods such as compressor-based systems. In addition, they are ideal solutions for applications where the cooling system must be portable or subjected to motion such as in sound and lighting equipment.
To provide a complete solution, EIC offers packaged systems comprised of enclosures and cabinets with integrated cooling assemblies. These systems are designed to protect and cool electrical/electronic systems in a wide range of entertainment and sports venues including led scoreboards, audio/video equipment and security systems. These integrated cooling systems offer superior performance with excellent temperature uniformity, resulting in lower electronic component temperatures, increased operational life and reliability (MTBF).
Additionally, the compact size and weight of EIC’s cabinet coolers allows them to fit a wide range electronic enclosures, electrical cabinets and sub-racks. Standard product modifications are also available to meet customers’ exact needs such as custom sizes, doors, holes, cutouts, colors and accessories to reduce assembly time, and for easy integration into new or existing systems.
With the rugged stainless steel construction, reliable performance and flexibility these advanced thermoelectric systems offer, designers can reduce equipment size, weight, and power with improved cooling, corrosion resistance and hazardous location protection. Whether the application requires an off-the-shelf or custom system, EIC’s engineers will help find the solution to best meet your cooling needs.
The following examples highlight the wide range of applications, environments, and clients who rely on our enclosures and cooling systems to safeguard their critical electronics:
Additional applications of EIC products can be found in many amusement and theme park related settings including:
- Sound and Light Equipment
- Ticket Vending Machines
- Audio and Video Systems
- Network and Communications Gear
- Security Cameras, Systems and Monitors
